Name: Digital Multimeter DMM-168
Brand: Tecpel
SKU: DMM-168
Availability: OutOfStock

Digital Multimeter DMM-168

(No reviews yet) Write a Review

SKU:

DMM-168

MPN:

DMM-168

Weight:

285.00 Grams

Description
Warranty Information
Additional Information

Description

TECPEL Digital Automobile Multimeter - DMM-168

3 3/4 digit, Automobile, 165 × 78 × 42.5 mm

The DMM-168 from Tecpel is a handheld 3 3/4 digit (3,999) Digital Automobile Multimeter. It is the perfect instrument for circuit/electric equipment maintenance and repair because of its comprehensive functionality, consistent performance, and high precision. The meter contains a multipurpose electric meter for True RMS and temperature monitoring in addition to three basic capabilities for measuring voltage, current, and resistance. DC Voltage (DCV), DC Current (DCA), AC Voltage (ACV), DC Current (DCA), Resistance, Frequency, and Temperature Measuring Range are some of its measurement parameters. RPM function, Platinum Dwell-Tester for 4CYL, 5CYL, 6CYL, and 8CYL engines, Diode Measurement, Automatic Shift, Beeper, and Auto Shut Off are characteristics of the device.

This digital multimeter provides:

Dimension: 165 × 78 × 42.5 mm

DC Voltage (DCV): 400mV / 4V / 40V / 400V / 600V

DC Current (DCA): 400uA / 4000uA / 40mA / 400mA / 10A

AC Voltage (ACV): 400mV / 4V / 40V / 400V / 600V

AC Current (DCA): 400uA / 4000uA / 40mA / 400mA / 10A

Resistance (Ω): 400Ω / 4kΩ / 40kΩ / 400kΩ / 4MΩ / 40MΩ

Frequency: 10Hz ~ 400Hz

Temperature Measuring Range: -20 ~ 1000℃

Platinum Dwell-Tester: 4CYL、5CYL、6CYL、8CYL

Series Information

Tecpel Co. Ltd. has over 20 years of experience in the Test and Measurement market. They have set up over 50 country distributors worldwide. Their products are exported to Europe mainly. The confidence they have in their products is reflected in their one-year warranty.

Their product lines include power supplies, oscilloscopes, electronics & electrical meters and testers, Thermometer, sound level meters, etc.

About Tecpel Multimeter:

A multimeter or a multi-tester, also known as a VOM (volt, ohm, milli-ammeter), is an electronic measuring instrument that combines several measurement functions in one unit. A typical multimeter can measure voltage, current, and resistance. Analog multimeters use a micro-ammeter with a moving pointer to display readings.

Tecpel is regarded as one of the leading Taiwanese manufactures of high quality test and measurements, which provide different types of multimeter:

UT Series: Digital Multimeter

GOM Series: Micro-Ohm Tester

DMM Series: Digital Multimeter / True RMS Digital Multimeter / Pocket-size Digital Multimeter / Digital Multi-function Meter

TR-55i Series: Current signal recorder / voltage signal recorder

MCR Series: Signal recorder

UT Series: Digital Multimeter / Digital Distance meter

VD Series: Non Contact Voltage detector

AMM Series: Analog Multimeter /

TA Series: Thermocouple Adaptor

Documents

You may be interested to see this product's catalog. If so, please click to view the DMM-168 datasheet.

View AllClose

Warranty Information

One Year Warranty

View AllClose

Additional Information

DC Voltage (DCV):	400mV / 4V / 40V / 400V / 600V
DC Current (DCA):	400uA / 4000uA / 40mA / 400mA / 10A
AC Voltage (ACV):	400mV / 4V / 40V / 400V / 600V
AC Current (DCA):	400uA / 4000uA / 40mA / 400mA / 10A
Resistance (Ω):	400Ω / 4kΩ / 40kΩ / 400kΩ / 4MΩ / 40MΩ
Frequency:	10Hz ~ 400Hz
Temperature Measuring Range:	-20 ~ 1000℃
DC Voltage Deviation:	±(1%)
DC Current Deviation:	±(2%)
AC Voltage Deviation:	±(2%)
AC Current Deviation:	±(2.5%)
Resistance Deviation:	±(1.5%)
Frequency Deviation:	±(0.1%)
Temperature Deviation:	±(2.0%)
Platinum Dwell-Tester:	4CYL、5CYL、6CYL、8CYL
Working Environment:	-10~60°C / lower than 75%RH without dew
Storage Environment:	0~40°C / lower than 75%RH without dew
Elevation Limitation:	Lower than 1,000 meters
Power Supply:	DC 9V Battery X1
Dimension:	165 × 78 × 42.5 mm
Weight:	Approx. 285g (Battery including)
