Open Impeller Pulp Pump-ESK

Description

The ESK series open-impeller pulp pump is a technologically advanced design developed through years of experience and incorporating both domestic and international innovations. It is highly efficient for handling fiber, mud, and paper pulp with a consistency of up to 5%, as well as liquids with up to 30% solid content. The pump is suitable for a wide range of industries, including papermaking, metallurgy, salt collection, drainage, and power plants. Its casing features an end-suction and radial discharge design, with the discharge centerline and shaft aligned in the same vertical plane, all securely fixed on a robust base plate. The front and back wear plates are designed with a modular structure to allow easy replacement when wear occurs, ensuring efficient performance and prolonged lifespan.

Operation Conditions

• Pulp Consistency: ≤6%
• Solid Content: ≤30%
• Max Viscosity: 300 cP at normal temperature (24℃)
• Working Temperature Range: -20℃~120℃ (Specify if exceeding 100℃)
• Max Allowable Working Pressure (MAWP): PN1.6 MPa

Specifications

• Pump Inlet: DN100–DN500 mm
• Pump Outlet: DN80–DN500 mm
• Capacity (Q): 20–2300 m³/h
• Head (H): 7–60 m
• Operating Speed:
• 8P: 750 rpm
• 6P: 980 rpm
• 4P: 1450 rpm
• 2P: 2900 rpm

Direction of Rotation

The pump rotor rotates clockwise when viewed from the motor towards the pump.

Applications

• Soda and Inorganic Salts: Ammonia salt blending, pure soda, soda from ammonia soda processes, caustic soda, and others.
• Metallurgy: Electrolytic copper and nickel solutions, sodium aluminate liquor, and acid solutions for metal production.
• Iron and Steel Industry: Electroplating, scouring, and electrophoretic painting.
• Acid-Making Industry: Hydrochloric acid, nitric acid, sulfuric acid, phosphoric acid, and related substances.
• Petrochemical Industry: Petroleum refining, splitting, and separation processes.
• Paper-Making Industry: Pulp digestion, green liquor, bleaching liquor, and concentrated black liquor.
• Chemical Fertilizer Industry: Urea, ammonium nitrate, and other fertilizers.
• Fermentation Industry: Lactic acid, citric acid, beer, and food additives.
• Environmental Protection: Wastewaters with acid and alkali content.
